Solid Track Blocking (TB) provides horizontal bracing for studs and joists. The TB is thoroughly engineered for 12”, 16”, 24”, and custom stud layouts and has pre-punched guide holes for quick installation.
Features
- A variety of different lengths offered to fit all standard stud and joist sizes
- Available in 12”, 16”, and 24” spacing (special lengths available)
- Custom lengths available upon request
- Pre-punched quide holes for quick attachment
- One-piece assembly
TB Submittal Download
Material Composition
- Mill certified steel
- ASTM A653/A653M
- 54 mil
– 57 ksi yield strength
– 65 ksi tensile strength
– G60/G90 galvanized coating
Nomenclature
Quantity / Order Information
| Model No. | Stud Dimensions | ||
|---|---|---|---|
| Width | * Flange | Spacing | |
| TB250-*-S12-54 | 2 ½” | 125/162/200 | 12” |
| TB250-*-S16-54 | 2 ½” | 125/162/200 | 16” |
| TB250-*-S24-54 | 2 ½” | 125/162/200 | 24” |
| TB350-*-S12-54 | 3 ½” | 125/162/200 | 12” |
| TB350-*-S16-54 | 3 ½” | 125/162/200 | 16” |
| TB350-*-S24-54 | 3 ½” | 125/162/200 | 24” |
| TB362-*-S12-54 | 3 ⅝” | 125/162/200 | 12” |
| TB362-*-S16-54 | 3 ⅝” | 125/162/200 | 16” |
| TB362-*-S24-54 | 3 ⅝” | 125/162/200 | 24” |
| TB400-*-S12-54 | 4” | 125/162/200 | 12” |
| TB400-*-S16-54 | 4” | 125/162/200 | 16” |
| TB400-*-S24-54 | 4” | 125/162/200 | 24” |
| TB600-*-S12-54 | 6” | 125/162/200 | 12” |
| TB600-*-S16-54 | 6” | 125/162/200 | 16” |
| TB600-*-S24-54 | 6” | 125/162/200 | 24” |
| TB800-*-S12-54 | 8” | 125/162/200 | 12” |
| TB800-*-S16-54 | 8” | 125/162/200 | 16” |
| TB800-*-S24-54 | 8” | 125/162/200 | 24” |
| TB1000-*-S12-54 | 10” | 125/162/200 | 12” |
| TB1000-*-S16-54 | 10” | 125/162/200 | 16” |
| TB1000-*-S24-54 | 10” | 125/162/200 | 24” |
| TB1200-*-S12-54 | 12” | 125/162/200 | 12” |
| TB1200-*-S16-54 | 12” | 125/162/200 | 16” |
| TB1200-*-S24-54 | 12” | 125/162/200 | 24” |
