Fire Track Blocking (FTB) provides horizontal bracing for studs and joists. The FTB is thoroughly engineered for 12”, 16”, and 24” stud layouts and has pre-punched guide holes and precut flanges to fit the stud cavity for quick installation.
Features
- A variety of different lengths offered to fit all standard stud and joist sizes
- Available in 12”, 16”, and 24” spacing
- Custom lengths available upon request
- Pre-punched guide holes for quick attachment
- One-piece assembly
- Fills the whole stud cavity
Material Composition
- Mill certified steel
- ASTM A653/A653M
- 54 mil
– 57 ksi yield strength
– 65 ksi tensile strength
– G60/G90 galvanized coating
Nomenclature
Gallery
Quantity / Order Information
Model No. | Stud Dimensions | ||
---|---|---|---|
Width | * Flange | Spacing | |
FTB250-*-S12-54 | 2 ½” | 125/162/200 | 12” |
FTB250-*-S16-54 | 2 ½” | 125/162/200 | 16” |
FTB250-*-S24-54 | 2 ½” | 125/162/200 | 24” |
FTB350-*-S12-54 | 3 ½” | 125/162/200 | 12” |
FTB350-*-S16-54 | 3 ½” | 125/162/200 | 16” |
FTB350-*-S24-54 | 3 ½” | 125/162/200 | 24” |
FTB362-*-S12-54 | 3 ⅝” | 125/162/200 | 12” |
FTB362-*-S16-54 | 3 ⅝” | 125/162/200 | 16” |
FTB362-*-S24-54 | 3 ⅝” | 125/162/200 | 24” |
FTB400-*-S12-54 | 4” | 125/162/200 | 12” |
FTB400-*-S16-54 | 4” | 125/162/200 | 16” |
FTB400-*-S24-54 | 4” | 125/162/200 | 24” |
FTB600-*-S12-54 | 6” | 125/162/200 | 12” |
FTB600-*-S16-54 | 6” | 125/162/200 | 16” |
FTB600-*-S24-54 | 6” | 125/162/200 | 24” |
FTB800-*-S12-54 | 8” | 125/162/200 | 12” |
FTB800-*-S16-54 | 8” | 125/162/200 | 16” |
FTB800-*-S24-54 | 8” | 125/162/200 | 24” |
FTB1000-*-S12-54 | 10” | 125/162/200 | 12” |
FTB1000-*-S16-54 | 10” | 125/162/200 | 16” |
FTB1000-*-S24-54 | 10” | 125/162/200 | 24” |
FTB1200-*-S12-54 | 12” | 125/162/200 | 12” |
FTB1200-*-S16-54 | 12” | 125/162/200 | 16” |
FTB1200-*-S24-54 | 12” | 125/162/200 | 24” |
